Nickel Tubes
| Standards | ASTM B161, ASTM B163 |
| Available Grades | 1 grades (1 in stock) |
Available Grades for Nickel Tubes
Click a grade to view its chemical composition and mechanical properties inline.
Nickel 200
Nickel (Unalloyed)UNS: N02200
Commercially pure nickel. Excellent resistance to alkalis and fluorides. For chlor-alkali, food processing, and chemical heat exchangers.
Chemical Composition (wt%)
| Ni | 99.0 min |
| C | 0.15 max |
| Mn | 0.35 max |
| Fe | 0.40 max |
| S | 0.01 max |
| Si | 0.35 max |
| Cu | 0.25 max |
Mechanical Properties
| Tensile Strength | 380 MPa – 550 MPa |
| Yield Strength | 100 MPa – 275 MPa |
| Elongation (min) | 30% |
| Hardness | 120 HB |
| Elastic Modulus | 204 GPa |
In stock
In-Stock Dimensions
Nickel 200
26.7*2.77 42*2.77 48.3*3.68 114*3.05 114*6.02
Nickel Tubes Weight Calculator
Calculated Weight
Per piece17.397 kg
Imperial38.353 lbs
Cost Estimate (FOB Baoji)
Price tierPrototype / R&D
Unit price$75.6/kg
Estimated total$1,315.18
* Reference pricing only. Actual quote depends on specifications, tolerances, and certification requirements.
Grade 5 Properties
Density4.43 g/cm³Tensile895–1000 MPaYield828–910 MPaElongation10%
Quality & Certification
📋
Material Test Certificate
EN 10204 Type 3.1/3.2 MTC with every shipment. Full heat traceability.
🔬
Testing & Inspection
UT, PMI, tensile test, hardness test. Third-party inspection available.
✅
ISO 9001:2015
All partner mills certified. ASTM / ASME / AMS / GJB compliant.
🚚
Fast Delivery
Stock items: 3 days. Custom orders: 15–45 days. FOB Baoji / CIF worldwide.
